Fujitsu Interactive Panel IWB
- Stock: In Stock
- Reward Points: 400
- Model: IW862 Ultra
- Weight: 62.35kg
$53,800
Price in reward points: 200
More From Same Category
| Fujitsu Interactive Pane Technical Details | |
| Accessories | AC power cable：British standard power cord (3 meters) USB cable：1 USB 2.0 (5 meters) HDMI cable：1 HDMI 1.4 (3 meters) Writing pen：Smart pen x 2 Pen Tray：1 Remote control：1 Operation instruction：1 |
| Audio | Sound channel：2.2 channel Speaker：2×8W + 2×18W (Total 52W) Sound pressure level：86dB Peak power：108W |
| Built-in sensors / readers | NFC reader：Yes Ambient light sensor：Yes CO2 sensor：Yes Temperature sensor：Yes Humidity sensor：Yes |
| Connectivity | HDMI：1 HDMI-Out (4K 60Hz), 3 HDMI-In (HDMI 2.1) USB：3 USB 2.0, 2 USB 3.0 USB Type-C®：1 USB Type-C® 65W Audio output：1 RS232 control：1 LAN In：1 GIGABIT LAN (RJ45) LAN Out：1 GIGABIT LAN (RJ45) Touch Out：2 USB 2.0 SPDIF：1 SPDIF Wi-Fi：Yes, Wi-Fi 6, Dual Band |
| Dimensions / Weight | Power key location & number：1 Side physical key Dimension L x H x D：1,958 x 1161 x 79 mm Dimension (package) L x W x H：2,123 x 280 x 1308 mm Net weight：62.35kg Gross weight：83.85kg Thickness of machine and wall mount：109 mm (9,060 G) Wall-hanging screw spec：M8 x 25 mm VESA：800 x 600 mm |
| Electrical values | Rated voltage range：100 V – 240 V Rated frequency range：5A |
| Environment | Operating temperature：0°C~40°C Storage temperature：-10°C~60°C Storage humidity：10%~80% RH Non-Condensing Operating humidity：10%~80% RH Non-Condensing |
| Microphone | Built-in microphone array：8 Audio pickup range：0-8 meters |
| Miscellaneous | Color：Black Password lock：Support USB key Panel lock：Support Smart shared USB：Support Switch sources：Support Scheduled power up / shutdown：Support Multiple-windows：Support |
| Order information | Order code：HLIWB0039A-01 EAN code：8888551551743 |
| Picture performance | Panel backlit：DLED Screen surface treatment：AG tempered glass Mohs hardness level 9 Contrast – typica：4,000:1 Viewing angle (h/v) - typical：178° Color performance：1.07 billion colors (10bit) Brightness – typical：400 cd/m² (Typ) Flicker-free technology：Yes Low blue light：Yes Anti-Glare filter：Yes Picture in Picture (PIP) mode：Yes Picture by Picture (PBP) mode：Yes |
| Power consumption (typical) | Standby Power：≤0.5 W Typical power* [1]：330 W |
| Quality and reliability | MTBF：50,000 h |
| Size and resolution | Aspect ratio：16:9 Resolution (native) ：3,840 (H) x 2,160 (V) Picture size (H x V) ：1,895.04 x 1065.96 mm Pixel pitch：0.4935 mm Response time：8 ms (Typ) Refreshing frequency：60 Hz |
| System | CPU (Central Processing Unit)：Quad core A73 x 4 + Quad core A53 x 4 GPU (Graphics Processing Unit)：Quad core Mali G52MP8 System memory：8 GB Storage：64 GB OS：Android 11 |
| Touch system | Sensing type：Capacitance touch recognition Touch point：40 points touches Minimum object size：3 mm (Active pen), 8 mm (Passive Pen) Touch tool：Passive Capacitive Pen ，Active Capacitive pen，Finger touch Response time：≤10 ms Accuracy：±1 mm (Active Pen), ±2 mm (Passive Pen) Hand & Pen Separation：Support Palm Rejection：Support Pressure：4096 level |
| Warranty | Standard warranty：3 years (depending on country) Service level：On-site |
| Wireless Screen Mirroring | Wireless Screen Mirroring：Support PIN code connection mode：Support both static and dynamic pin codes Maximum split screens：9 Maximum devices projection：9 Simultaneous (Android mode) Self-hotspot Screen Mirroring：Support Native AirPlay protocol for Screen：Support Native Chromecast protocol for Screen：Support Native Miracast protocol for Screen：Support Mirroring of Panel display to client devices：Support Reversely control Windows / MacOS：Support, client software required Multi-Panels synchronization：Support Built-in moderator console：Yes |
